Vertical and horizontal CNC milling machines: troubleshooting guides, alarm references, and procedures for common makes and models.
Most CNC mill faults come from three places: the control, the servos, or the utility systems the machine quietly depends on. Experienced techs triage by symptom. Tool changer fault usually means low air pressure. Servo overtravel means the machine was crashed. A spindle fault points at coolant first.
Check air pressure. Check coolant level. Check the way-oil reservoir. Look for chips behind a way cover that might be jamming an axis. A large share of the broken-machine calls you will get are fixed in under five minutes by checking these four things. The longer you put it off, the more time you waste staring at the control reading alarm codes.
Control software can show stale parameters after a power event. Absolute encoder batteries die. A corrupted part program can look like a servo fault. Before you swap any hardware, verify the program against a known-good backup. On Haas with a 2013-or-newer control, ATC faults after a crash almost always start at the proximity sensor alignment. On Fanuc-controlled machines, the absolute-encoder battery-low warning is not cosmetic. Replace it with the machine powered on. Losing home on a three-axis mill costs a day. Losing it on a five-axis costs a week.
A spindle that runs hot will grow in Z. Parts drift out of spec mid-cycle. You check your offsets, they look right, the next part is fine again. This is thermal growth. The fix is usually in the shop HVAC, not the machine. If your shop does not hold temperature inside a tight band, expect drift on any long cycle. Log it against asset temperature so you can tell whether the mill is moving or the room is.
Call the OEM for ball-screw replacement, for spindle bearing changes, for anything that involves re-mastering a rotary axis, and for any crash where the axis geometry might be off. Fixing these in-house usually costs more in lost production than the service call would have.
